Resolver Based

120 VAC Input

8.5 x 6.5” LED Display

Requires External Rack and Modules

Output Enable Modes & Standard Features

Separate Input/Output Rack with Modules

48 AC and/or DC Transistor Outputs

*2 Output Racks and 2 Output Rack Cables are required with 48 Output Systems

Communications and Expanded Operator Enable Features are Standard

Available Options:

F – Additional Setpoint/Program Storage ($300.00)

G – Gray Code Position Output (8 bit) ($100.00)

H – 12 Bit Resolution ($350.00)

L – Leading & Trailing Edge Speed Compensation ($150.00)

V – Vibration Protection ($50.00)

W – Washdown Boot ($105.00)

*If combining options please call the factory, 815-389-2620
